Audioquest Dragonfly Copper DAC

Gordon Rankin: Well, we had expected the product to arrive much sooner. We had been in development for some time when COVID hit and everything kind of halted, creating a pretty big gap in development.

When we started again, the plan for the next-generation DragonFly was very specifically focused on creating a more powerful version of what already existed. The project was codenamed “Ruby,” and, like Black, Red, and Cobalt, it would be an MQA renderer, which significantly impacted many of the project’s design criteria.

But then MQA pretty much went away, and the Ukraine war started, both of which altered our course. Ukraine supplies a huge number of natural resources that were used in discrete components in all the DFs, which are now unavailable, so we had to source new parts and reconsider our design goals and development strategy.

Gordon Rankin: A USB DAC basically takes byte frames as they come, then converts that data to a 32-bit buffer that is next converted to I²S and finally sent to the DAC chip.

With MQA, you couldn’t just convert — you had to process each frame received by the Host to determine whether it’s MQA or just standard PCM. If MQA was identified, then you had DSP responsibilities to process the data. That requires a processor with more guts, which then means more power drawn from the Host (over USB).

Removing MQA from the product-development mandate opened new possibilities for the parts we could use and how they could be applied.

Gordon Rankin: It was pretty much a restart.

Removing the Fly’s ability to render MQA meant there would be less DSP work in the processor, so we could use one that required less power.

One of the biggest requests we received from customers was for more headphone power, so we approached ESS and they delivered the ES9218 — an integrated DAC/headphone combo. This gave us two times the headphone power of any previous DragonFly and lots of nice digital filters that we used in Cobalt.

But the big-time component was finding capacitors that were exceptional for the job. You can read data sheets all day long but to get things in a place that really exceeded Cobalt required concentrated testing and significant changes in board layout.

Garth Powell: The case.

We knew from the development of our Mythical Creature interconnects that a linear material that’s highly conductive at radio frequencies, such as a thick, dipped-process copper plate, would afford the DragonFly circuits superior noise dissipation. The direct-plated copper is far more effective at draining away induced radio-frequency signals than polymer, brass, zinc, or aluminum.

It’s a small detail, but one that is quite audible. And, of course, once the casework was settled, the model name became obvious.

Gordon Rankin: Cobalt contains some of the filtering technology featured in JitterBug, and it’s generally inadvisable to use two filters in series, so partnering Cobalt with JitterBug didn’t always produce desirable results.

That isn’t the case with Copper. (Alright, pun intended.)

Copper is the quietest DragonFly we’ve ever produced, but even more noise can be rejected with the addition of a JitterBug.

Gordon Rankin: I think USB-C was set to become a global standard as defined by the European Union as far back as 2015. That of course didn’t happen, but it has pretty much been a staple for several years. The big problem of course is the dimensions of USB-C and the proximity to other ports. You really need a cable of some kind. There are also a lot of streamers and computers that still have USB-A connectors.

From a practical, real-world perspective, DragonFly owners often lost their units’ caps. And, as AudioQuest is always looking for ways to provide more for less, we figured doing away with the cap and having the DragonTail preinstalled was a simple way to give our customers what they really need while saving a small expense.

For those who want to connect their DragonFlys to a USB-A device, removing the DragonTail is a simple step — and the DragonTail remains a far more valuable, functional accessory.

Gordon Rankin: First, DragonFly negotiates with the Host, informing it that it has its own internal volume control. Giving control to DragonFly means the Host will deliver bit-true music to the DragonFly.

Sure, you could add volume control knobs and touchscreens, but those are both easily broken and require more power.

Gordon Rankin: Simple: USB DACs that use High Speed USB draw between two to 10 times more power than going with Full Speed USB, which tops out at 24/96.

Just because you can do something, doesn’t mean you should. What happens when a USB DAC is processing 32/384 frames? Usually, the result is barely breaking 16/44.1 specifications. The current draw, the signal-to-noise ratio, the processing, the heat… it’s all throwing everything into the toilet.

Plus, a significant number of our customers use DragonFly with their mobile phones. Compared to a DAC running High Speed USB and 32/384 processing, Copper will not affect the phone’s battery much at all.

Gordon Rankin: The greatest joy about working with AudioQuest and DragonFly is being in an airport or on a plane or wherever and seeing someone using one of the DragonFlys that I helped create.

The discussion around DragonFly’s versatility — the ways and places it can be used — is just amazing. Since I also design pro-audio equipment and work with musicians, I often get to share DragonFly with people in those worlds, and they are stunned by the output capabilities of the DragonFly line.

Most of these people have a lot of downtime and they say they use DragonFly while watching movies on the tour bus and as a production tool, working on and evaluating their music.

DragonFly takes any Host with a USB port to the next level, regardless of how it’s used, which makes it valuable to a wide range of listeners. I just love that.

A DAC (Digital-to-Analog Converter) translates the digital audio data on your phone, laptop, or tablet into the analog electrical signal your headphones or speakers need. Every device has a built-in DAC, but most are inexpensive components designed to minimise cost. An external DAC like the DragonFly Copper bypasses your device’s inferior converter and replaces it with a high-precision component — resulting in cleaner, more detailed, more dynamic sound.

Yes. The DragonFly Copper supports both iOS and Android. USB-C iPhone (iPhone 15 and later) and USB-C Android devices connect directly using the included DragonTail adaptor. Older Lightning iPhones require Apple’s Lightning-to-USB Camera Adapter (sold separately by Apple) plus the DragonTail adaptor.

The Copper is a significant step forward in every key area. It delivers twice the headphone amp output power of the Cobalt, uses the newer ESS9218 DAC chip, adds a copper-plated RF-shielding case for measurably lower noise, and draws 25% less current from your device’s battery. It is the most capable and technically refined DragonFly ever produced.

Yes, every streaming and local playback app works with the DragonFly Copper — Spotify, Apple Music, Tidal, Amazon Music, Qobuz, YouTube Music, and any local file player. For the best results, use a lossless or Hi-Res tier such as Tidal HiFi, Apple Music Lossless, or Qobuz Studio, where the DragonFly Copper’s full capabilities are realised.

No. On macOS and Windows the DragonFly Copper is entirely plug-and-play — no drivers or software required. On iOS and Android it integrates natively with the device’s audio system. Volume is managed through your device’s standard controls or within your music app.

Yes. The 3.5mm output functions as both a headphone output and a line-level preamp output. Use a 3.5mm-to-RCA cable to connect to any amplifier or set of active/powered speakers. This turns your phone or laptop into a high-quality source for your entire home audio system.

The LED indicator on the DragonFly illuminates in different colours to confirm which audio format is being decoded — giving you real-time confirmation that your lossless or Hi-Res files are playing at full quality. Each colour corresponds to a specific sample rate or format category.

The AudioQuest DragonFly Copper is scheduled for release in Summer 2026. Use the notification form on the product page to be alerted as soon as stock arrives, or add it to your cart now to secure your order position.
